Applied Solutions

NAVI AI Mercury

The client company is a coil manufacturer that wants to introduce the Vision Solution that checks the coils for welding within the correct range.

If a rule-based inspection is introduced to check that the coils tilted in different directions are welded in the correct position, it will take a long time to review various points, including the welding point, the direction of the coils, and the location of the coils within the welding point.

 LAON PEOPLE provides a vision solution that categorizes images collected in the field into accepted/defective products and accurately classifies accepted/defective products just by deep learning.

Overview of Inspection

• ​Inspection Field: Metals
• Inspection Parts: Coil
• Inspection Type: Inspection for the Defect on Coil Welding
• Inspection Solution: NAVI AI Mercury

Features and Benefits of LAON PEOPLE

• ​Conducts an inspection through deep learning (provides the Vision Solution)

Applied Solution

3D Camera

One of the test items that are actively expanding applications using LAON PEOPLE 3D camera is welding inspection. Defective inspections of welding applied to cars, pipe manufacturing, and H beams can also be more easily performed with 3D cameras.





A 3D image is not required for welding inspection. Profile mode can also be applied for welding bead tracking inspection of a constant structure, as shown in [figure 2]. Continuous mode inspection allows inspection of height, cut, length, width, and angle of welding at the same time.




[figure 3] below shows detection of defects when the welding width and height are lowered in the middle of the bead.




[figure 4] is an application that can be checked at once, in addition to welding inspection, to the height of tightening bolt. In the case of a bolt welding inspection, the use of a dual camera minimizes the shaded area, making it more accurate.




Dual Camera Mode is one of the inspection methods using multiple cameras to remove laser or camera shaded areas caused by the product structure and can be easily implemented using API provided.

Applied Solution

LPMVC-EE500(5M/Color) + NAVI AI SW

Clients wanted to introduce vision solutions to the process of laser welding point defect inspection during product production.

In an environment where visual inspection is impossible, it is required to identify defective types with a vision solution in a more accurate and faster time to detect various types of defects as a single solution.

Clients were having difficulty in inspecting defective/accepted products because they had to inspect various defect types for the purpose of preventing welding debris in an environment where visual inspection was impossible immediately.

LAON PEOPLE provided a vision solution that enables inspection of defective/accepted products through learning of deep learning after classification of defective types and products.

Overview of Inspection

• Inspection Field: Metal Plate
• Inspection Part: Welding Points on Metal Plates
• Inspection Type: Hall, pit, etc. that may occur during laser welding.
• Constitution of an Inspection Solution
  - Inspection Camera: LAON PEOPLE LPMVC-EE500(5M/Color)
  - Inspection S/W: NAVI AI Trainer, NAVI AI of LAON PEOPLE
  - Lens: 25mm
  - WD: About 500mm





Contents of Inspection

Type of defects from laser welding
[Hole] Defect showing opposite side of welding surface
[Pit] Defect pitting like holes or on edge of welding point

Learning type of accepted/defective products

Strengths of LAON PEOPLE

• Real-time inspection speed
• Automatic inspection solution: it is possible to convert and control the image without operator's intervention.

• Operator can participate in learning, enabling customized inspection of defect types.




Applied Solutions

LPMVC-EE500(5M/Color) + NAVI AI SW

The client company who is the refrigerator manufacturer wanted to introduce vision solution to the inspection process for the defective compressor parts that can occur during the product processing process.

It was required to resolve the types of defects identified by the existing visual inspection with a vision solution in accurate and faster time and detect various types of defects as a single solution.

The role of optics in vision inspection is very important, but the process of inspection was delayed because the lighting on the market did not solve the compressor's processing surface defect.

LAON PEOPLE created an optical condition that can analyze the pattern of defective machined surfaces using its own lighting, and provided a vision solution that enables inspection of defective/accepted products through deep learning after simple classification of optical patterns.

Overview of Inspection

• Inspection Field: Home appliance parts
• Inspection Parts: Refrigerator compressor
• Inspection Type: Poor surface machining, scratches, dent, etc. that may occur during the compressor processing process
• Configuration of Inspection Solution
  - Configuration of Inspection Solution
  - Inspection S/W: LAON PEOPLE NAVI AI Trainer, NAVI AI
  - Lens: 8mm
  - Lighting: LAON PEOPLE Self-produced Lighting (Color Ring)





Contents of Inspection

Defect Type of Compressor
[Poor Surface Machining] Poor Machining of Compressor Surface
[Scratches] Scratches on the Surface and Edge of Compressor
[Dents] Dents on the Surface and Edge of Compressor

Features and Benefits of LAON PEOPLE

• ​Fast inspection speed (within 3.5 seconds per defect type)
• Customized optical design enables robust inspection for fine details

• Automatic inspection solution: image conversion and control without inspector's intervention

• Enabling customized testing of defect types as the inspector can participate in learning
